Capacity

kg

0.3, 0.6, 1, 1.5, 2, 3

Sensitivity

mV/V

0.9±0.1

Linearity error

%FS

±0.01

Hysteresis error

%FS

±0.01

Repeatability error

%FS

±0.005

Creep

%FS(5mins)

±0.015

Four corners error

%FS

±0.02

Zero output

%FS

±2.0

Temperature effect on zero

%FS/10℃

±0.02

Temperature effect on sensitivity

%FS/10℃

±0.02

Input resistance

Ω

410±10

Output resistance

Ω

350±2

Insulation resistance

MΩ(50V DC)

≥5000

Reference excitation voltage

V(DC/AC)

1-10

Compensated temperature range

℃

-10~＋40

OperatingTemperatureRange

℃

-10~＋60

Safe overload

%FS

150

Protection Class

IP65

Cable

Φ3mm×0.4m

Input：Red(＋) Black(－)

Output：Green(＋) White(－)

Recommended platform size

mm

200×200
