Capacity

kg

5 , 10 , 20 , 30 , 50 , 100

Sensitivity

mV/V

2.0±0.1

Linearity error

%FS

±0.02

Hysteresis error

%FS

±0.02

Repeatability error

%FS

±0.01

Creep

%FS(5mins)

±0.02

Four corners error

%FS

±0.02

Zero output

%FS

±2.0

Temperature effect on zero

%FS/10℃

±0.02

Temperature effect on sensitivity

%FS/10℃

±0.02

Input resistance

Ω

410±10

Output resistance

Ω

350±2

Insulation resistance

MΩ

≥5000

Reference excitation voltage

V(DC/AC)

1-10

Compensated temperature range

℃

－10~＋50

OperatingTemperatureRange

℃

－20~＋60

Safe overload

%FS

150

Protection Class

IP65

Cable

Φ5mm×2m

Input：Red(＋) Black(－)

Output：Green(＋) White(－)

Recommended platform size

mm

400×400
